Undetermined dimension fuel Heating piping systems using
Corrugated stainless steel tubes
|
|
· Coil length 20,30,50,60 meters,UP to 100m per roll
·PE UV resistant jacketing, can put under ground and inwall ,jacketing thickness is 0.5mm,other jacketing thickness is available upon customer's require.
· Jacketing Color is greyish white ,other color is available upon customer's require
The following dimensions are available:
|
1/2" |
3/4" |
1" |
5/4" |
|
DN 12 |
DN 16 |
DN 20 |
DN 25 |
|
| · Assembly Item & Material |
|
|
|
No.
|
Item
|
Material
|
|
1
|
Nut |
Brass |
|
2
|
Metal Hose
|
SUS304,SUS316L |
|
3
|
Gasket
|
350℃ High-temperature resistance seal |
|
4
|
Cir-Clip
|
Stainless Steel |
Metal Hose Installation Procedure please click here |
| ·Dimension and
Performance |
|
DN
|
φID
mm
|
δ
mm
|
meters per Coil
|
Bending Radius
mm
|
Maximum Applicable
Pressure kgf/cm2
|
Burst Pressure
kgf/cm2
|
|
DN12
|
12
|
16
|
60
|
30
|
17.5
|
200
|
|
DN16
|
16
|
20
|
60
|
40
|
15
|
200
|
|
DN20
|
20
|
25
|
60
|
50
|
12
|
200
|
|
DN25
|
27
|
32
|
30
|
60
|
10
|
120
|
|
| |
|
|
|
